| 1. | 87713180 | [1] | PUMP | FARASSY., Internal Gear Pump; Incl Ref 2 & 4 |
| 2. | 87713195 | [1] | PUMP | BURPUMP, Internal Gear, Front Pump Superseded by part number: 87713180 |
| 3. | 87713208 | [1] | PUMP | BURPUMP, Internal Gear, Rear Pump |
| 4. | 87713196 | [1] | SEALING RING | BURSEALRING PLATE, Wear |
| 6. | 87713184 | [1] | SEAL,50mm ID x 80mm OD x 7mm Thk | BURRing, Shaft Seal |
| 7. | 800-1140 | [1] | SNAP RING,M40, Ext | CAS Superseded by part number: 370006 |
| 8. | 87516829 | [1] | CONTROL | BURStroking/A Hydraulic Control |
| 10. | 87713177 | [4] | WASHER | BURWASHER |
| 11. | 614-20045 | [4] | BOLT,Hex, M20 x 2.5 x 45mm, Cl 8.8, Full Thd | CASBOLT Superseded by part number: 86508588 |
| 13. | 87713209 | [1] | FLANGE COVER CAP | BURFLANGE, Intermediate |
| 24. | 87713197 | [1] | FLANGE | BURFLANGE, Intermediate |
| 25. | 87713200 | [4] | HEX SOC SCREW | BURSCREW, Scoket Head |
| 26. | 87713198 | [1] | SHAFT | BURSHAFT, Drive Thorugh Superseded by part number: 84407742 |
| 27. | 238-5239 | [1] | O-RING,0.139" Thk x 3.609" ID, -239, Cl 5, 75 Duro | CAS Superseded by part number: 87016952 |
| 28. | 238-5155 | [1] | O-RING,0.103" Thk x 3.987" ID, -155, Cl 5, 75 Duro | CAS Superseded by part number: 9828498 |
| 29. | 238-5258 | [1] | O-RING,0.139" Thk x 5.984" ID, -258, Cl 5, 75 Duro | CASO-RING Superseded by part number: 86014139 |
| 34. | 87713178 | [1] | CONTROL | BURASSY., Hydraulic Control |
| 35. | 87713185 | [1] | PISTON | BURPiston, Positioning, Complete |
| 36. | 87713187 | [1] | COVER | BURCover, Piston |
| 37. | 87713186 | [1] | COVER | BURCover, Piston |
| 38. | 829-23416 | [1] | THIN NUT,Thin, M16 x 1.5, Cl 05 | CASNUT, Hex |
| 39. | 864-8020 | [8] | HEX SOC SCREW,M8 x 20mm, Cl 8.8 | CAS Superseded by part number: 120228 |
| 40. | 238-5151 | [2] | O-RING,0.103" Thk x 2.987" ID, -151, Cl 5, 75 Duro | CAS Superseded by part number: 18438 |
| 41. | 87713192 | [2] | RING | BURGLYD-Ring, Turcon |
| 42. | 87713193 | [1] | SEAL KIT | BURKIT, Seal Hydraulic Control |
| 59. | 87516840 | [1] | PISTON | BURPositioning Piston |
| . . | 238-5014 | [2] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 5, 75 Duro | CAS Superseded by part number: 130282 |
| . . | 87713179 | [1] | PLATE | BURPLATE, Port |
| . . | 87713181 | [1] | MODULE | BURMODULE, Electric Control |
| . . | 87713182 | [1] | SCREW | BURSCREW, Locking |
| . . | 87713205 | [2] | SOLENOID | BURSOLENOID, Pair Proportional |
| . . | 87713206 | [1] | GASKET | BURGASKET, Serial Range: Pump-Control |
| . . | 87713207 | [1] | FLANGE COVER CAP | BURCOVER, Control Module |
| . . | 87516844 | [1] | SEAL KIT | BURSeal Kit for Hydraulic Control Stroking/A |
| . . | 87516833 | [1] | PLUG | BURSCREW, LOCK, 1-1/16 - 12 UN Plug |
| . . | 87516835 | [3] | PLUG | BURSCREW, LOCK, 7/16 - 20 UNF Plug |
| . . | 87516836 | [1] | PLUG | BURSCREW, LOCK, M33 x 2 Plug |
| . . | 87516837 | [1] | RING | BUR40 x 1.75 Retaining Ring |
| . . | 87516862 | [1] | SEAL KIT | BURKIT, SEALS, For Control Module |
