| . . | 87313549 | [1] | HYDROSTATIC PUMP,105 CC | BURPUMP, Tandem, Includes Parts On This Figure; Also Includes Figure 06-12 Superseded by part number: 84345381 |
| . . | 87313549R | [1] | REMAN-HYD PUMP | BRRTandem |
| . . | 87313549C | [1] | CORE-HYDRAULIC PUMP | BRRReturn Number |
| 1. | 863-6020 | [8] | HEX SOC SCREW,M6 x 20mm, Cl 12.9 | CASFront and Rear Pumps Superseded by part number: 86512135 |
| 8. | 238-5148 | [2] | O-RING,0.103" Thk x 2.737" ID, -148, Cl 5, 75 Duro | CAS Superseded by part number: 14460680 |
| 9. | 87441417 | [2] | RING | BURGuide; Front and Rear Pumps |
| 11. | 238-6012 | [2] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | CASPositioning Piston Rod; Front and Rear Pumps Superseded by part number: 9993141 |
| 12. | 87516845 | [2] | VALVE, PRESSURE RELI | BUREF Main Relief; Front and Rear Pumps; Component Parts Not Serviced Separately Superseded by part number: 87441421 |
| 13. | 87441430 | [1] | PRESSURE RELIEF VALVE | BURCharge Pressure Relief; Component Parts Not Serviced Separately; Includes (1) 87441428 Seal Lock Nut; Front Shaft End Pump |
| 14. | 87441431 | [1] | PRESSURE RELIEF VALVE | BURPressure Overide; Incl. Ref 15, 16; Front and Rear Pumps |
| 15. | 87441427 | [1] | LOCK NUT | BURSeal Lock Nut; If Used |
| 16. | 238-6010 | [1] | O-RING,0.07" Thk x 0.239" ID, -10, Cl 6, 90 Duro | CAS; If Used Superseded by part number: 86512844 |
| 17. | 87516854 | [1] | BEARING LINER | BURBearing |
| 18. | 864-10025 | [4] | HEX SOC SCREW,M10 x 25mm, Cl 8.8 | CASFront Pump Support Plate Superseded by part number: 120052 |
| 19. | 238-5159 | [1] | O-RING,0.103" Thk x 4.987" ID, -159, Cl 5, 75 Duro | CASFront Pump Support Plate Superseded by part number: 175156 |
| 20. | 87516850 | [1] | WEAR PLATE | BURWear Plate Assy |
| . . | 87516858 | [1] | WEAR PLATE | BHBWear Plate |
| 21. | 238-5152 | [1] | O-RING,0.103" Thk x 3.237" ID, -152, Cl 5, 75 Duro | IH Superseded by part number: 14461080 |
| 22. | 87441426 | [8] | RING | BURBolt Seal; Front Pump Support Plate |
| 23. | 238-5153 | [1] | O-RING,0.103" Thk x 3.487" ID, -153, Cl 5, 75 Duro | IHRear Pump Wear Plate Superseded by part number: 72186260, 259930 |
| . . | 87516832 | [1] | MODULE | BURPump Control Module, Complete; Incl. Ref 27-33C |
| 27. | 87441418 | [2] | SOLENOID VALVE | BURProportional Solenoid, Control Module; Front and Rear Pumps |
| 27A. | 87516859 | [2] | SOLENOID | BURProportional Control Module Solenoid Superseded by part number: 87484404 |
| 29. | 238-6121 | [2] | O-RING,0.103" Thk x 1.049" ID, -121, Cl 6, 90 Duro | CAS Superseded by part number: 511524 |
| 30. | 87444198 | [1] | GASKET | BURSolenoid Base; Front and Rear Pumps |
| 31. | 87441403 | [1] | GASKET | BURControl Module Cover; Front and Rear Pumps |
| 32. | 87441423 | [4] | BOLT,Skt Hd, M6 x 65mm, Gr 8.8 | BURSocket Head; Front and Rear Pumps |
| 33. | 87516860 | [1] | COVER | BURCover Solenoid Control Module |
| 33A. | 87516861 | [2] | PIN | BURCylinder Pin |
| 33B. | 87516863 | [1] | FILTER | BURFilter, Control Module |
| 33C. | 87516834 | [4] | PLUG | BUR9/16 - 18 UNF Locking Plug |
| 37. | 87516847 | [2] | O-RING,1.78mm Thk x 7.65mm ID | BUR7.65 x 1.78 O-Ring |
| 40. | 863-16090 | [4] | HEX SOC SCREW,M16 x 90mm, Cl 12.9 | SUM Superseded by part number: 2465671 |
| 41. | 864-8016 | [8] | HEX SOC SCREW,M8 x 16mm, Cl 8.8 | CAS Superseded by part number: 14306221 |
| . . | 238-6123 | [1] | O-RING,0.103" Thk x 1.174" ID, -123, Cl 6, 90 Duro | CAS Superseded by part number: 218774 |
| 47. | 87516830 | [1] | HYDRAULIC VALVE | BHBPort Plate With Valves |
| . . | 87516848 | [1] | SEAL KIT | BURSeal Kit For Port Plate With Valves |
| 48. | 87516846 | [1] | LOCK SCREW | BURM10 x 1 Locking Screw |
| 49. | 87516843 | [1] | NUT | BURM12 Hex Nut |
| 50. | 87516841 | [1] | COVER | BURStroking Piston Cover |
| 51. | 87516842 | [1] | COVER | BURStroking Piston Cover |
| 52. | 87516852 | [1] | FLANGE | BURIntermediate Flange, Front Pump |
| 53. | 87516865 | [1] | FLANGE | BURIntermediate Flange, Rear Pump |
| 54. | 87516857 | [1] | SHAFT | BURShaft Key, Front Pump |
| 55. | 87516866 | [1] | SHAFT | BURShaft Key, Rear Pump |
| 56. | 87516856 | [1] | WHEEL SET | BURGear Set |
| 57. | 87516855 | [1] | DRIVE SHAFT | BURThrough Shaft Superseded by part number: 84407759 |
| 58. | 87516853 | [1] | COVER | BURCharge Pump Cover |
| 60. | 87516849 | [1] | PUMP | BURInternal Gear Pump/A, Front Pump |
| 61. | 87516864 | [1] | PUMP | BURInternal Gear Pump/A, Rear Pump |
| . . | 87516851 | [1] | SEAL KIT | BURSeal Kit For Internal Gear Pump |
| 62. | 87516831 | [1] | FLANGE | BURDrive Flange |
