纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (04-02) - ALTERNATOR - MOUNTING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
365 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 1964860C1 | [1] | ALTERNATOR,24V, 60A, W/ Pulley | IHAssembly; See Figure 04-03 |
| 1. | 1964860C1R | [1] | REMAN-ALTERNATOR | BRRD150B CRAWLER DOZER TIER 3 (HYDRO), Assembly, MOUNTING (10/07-) |
| 1. | 1964860C1C | [1] | CORE-ALTERNATOR | BRRReturn Number |
| 2. | 2855590 | [1] | BRACKET | TORMounting Strap; Included With Engine Assembly |
| 3. | 4899031 | [1] | BOLT,Flng, M8 x 1.25 x 25mm | TOR Superseded by part number: 4899079 |
| 4. | 2855592 | [1] | NUT | TOR Superseded by part number: 17044925 |
| 5. | 2855591 | [1] | SCREW | TOR |
