纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (04-03) - ALTERNATOR ASSEMBLY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
354 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 1964860C1 | [1] | ALTERNATOR,24V, 60A, W/ Pulley | IH24V, 65 amp; Incl. 1 - 32 |
| . . | 1964860C1R | [1] | REMAN-ALTERNATOR | BRRD150B CRAWLER DOZER TIER 3 (HYDRO), 24V, 65 amp, ASSEMBLY (10/07-) |
| . . | 1964860C1C | [1] | CORE-ALTERNATOR | BRRReturn Number |
| 1. | 1964731C1 | [1] | HOUSING | IH |
| 3. | 1964737C1 | [1] | BUSHING,13.5mm ID x 20mm OD x 20mm L | IH |
| 4. | 3079389R1 | [1] | CAPACITOR | IH |
| 5. | 1964969C1 | [1] | SCREW | IH Superseded by part number: 86585709 |
| 9. | 3079392R91 | [1] | GOVERNOR | IHVoltage; Incl. 10 Superseded by part number: 79106750 |
| 10. | 1964968C1 | [1] | COMMUTATOR BRUSH | IH |
| 12. | A186194 | [2] | SCREW,M4 x 18mm | CAS |
| 13. | 1964738C1 | [1] | REPAIR KIT | IHHardware |
| 14. | 1546477C1 | [1] | SLEEVE | IH Superseded by part number: 140545A1 |
| 16. | 1964965C1 | [1] | RECTIFIER | IH |
| 17. | A187504 | [2] | SCREW | CAS |
| 18. | 1964966C1 | [1] | STATOR | IH |
| 19. | 1964964C1 | [1] | ROTOR | IH |
| 20. | 3079410R1 | [1] | RING | IH |
| 21. | 1964730C1 | [1] | BALL BEARING,12mm ID x 32mm OD x 14mm W | IH Superseded by part number: 24941650 |
| 22. | 495-21063 | [1] | WASHER,9/16" | CAS Superseded by part number: 18606 |
| 23. | 231-46110 | [1] | LOCK NUT,5/8"-18, GB | CAS |
| 26. | 1964727C1 | [1] | PLATE | IH |
| 27. | 1964726C1 | [1] | BALL BEARING,22.2mm ID x 56mm OD x 21mm W | IHDrive End |
| 28. | 1964725C1 | [1] | HOUSING | IH |
| 29. | 1964748C1 | [4] | SCREW | IHM5 x 132 Superseded by part number: 140549A1 |
| 30. | 1964750C1 | [4] | SCREW | IHM4 x 30 Superseded by part number: 140541A1 |
| 31. | 1964729C1 | [1] | SPACER | IH |
| 32. | 1964736C1 | [1] | FAN | IH |
| 34. | A189616 | [1] | PULLEY | CASNot Included In the Alternator Assembly; Purchase Separately Superseded by part number: 86976071 |
