纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (04-06) - HARNESS, ENGINE (LEFT-HAND SIDE AND REAR) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
416 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 893-11010 | [1] | LOCK WASHER,Ext Tooth, M10 | CAS Superseded by part number: 86632602 |
| 6. | L18331 | [4] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 8. | 87407206 | [1] | GROUND STRAP | IMOSTRAP, Serial Range: Engine-Chassis |
| 14. | 614-12025 | [1] | BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd | IH Superseded by part number: 300388 |
| 18. | 829-1410 | [1] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 29. | 493-11052 | [1] | LOCK WASHER,Ext-Int Tooth, 1/2" | CAS |
