纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (04-05) - HARNESS, ENGINE (RIGHT-HAND SIDE) - ALTERNATOR / STARTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
952 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 8605784 | [1] | STARTING MOTOR | FARSee Figure 04-01 |
| . . | 8605784R | [1] | REMAN-STARTER | FARD150B Tier 3 (10/07-) |
| . . | 8605784C | [1] | CORE-STARTER | MKTReturn Number |
| 4. | 1964860C1 | [1] | ALTERNATOR,24V, 60A, W/ Pulley | IHSee Figures 04-02, 04-03 |
| 4. | 1964860C1R | [1] | REMAN-ALTERNATOR | BRRD150B CRAWLER DOZER TIER 3 (HYDRO)ENGINE (RIGHT-HAND SIDE) (10/07-) |
| 4. | 1964860C1C | [1] | CORE-ALTERNATOR | BRRReturn Number |
| 6. | L18331 | [2] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 7. | 87370148 | [1] | WIRE HARNESS | BURMain, Engine; With ECU Connection; Attaches to Front Console Harness |
| 10. | L126713 | [2] | BOOT | CASElectricial |
| 12. | 515-24190 | [1] | CLAMP,3/4", Insul, 7/16" Bolt | CASUse Existing Hardware Superseded by part number: 86637999 |
| 13. | L71188 | [1] | CLAMP,15.75mm ID, 13.46mm Bolt Hole, P Type | CAS |
| 15. | 892-11012 | [1] | LOCK WASHER,M12 | CAS Superseded by part number: 412123 |
| 17. | 614-12025 | [1] | BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd | IH Superseded by part number: 300388 |
| 26. | 84235903 | [1] | WIRE | BURWire, Starter To Alternator |
