沃尔沃零件查询EW140 Cylinder blockSER NO 1001-1487 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
865 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
VOE11704870
|
[1] |
Cylinder block
|
|
| 2. |
|
[5] |
Bearing carrier
|
|
| 3. |
VOE6210370
|
[10] |
Screw
|
|
| 4. |
VOE483302
|
[10] |
Guide sleeve
|
|
| 5. |
VOE3976506
|
[1] |
Bushing
|
|
| 6. |
|
[4] |
Cylinder liner
|
|
| 7. |
VOE483898
|
[6] |
Plug
|
|
| 8. |
VOE11700782
|
[1] |
Plug
|
|
| 9. |
VOE11997805
|
[1] |
Plug
|
|
| 10. |
VOE11997807
|
[6] |
Plug
|
|
| 11. |
VOE3976594
|
[3] |
Plug
|
|
| 11A. |
VOE11709818
|
[1] |
Plug
|
ENG U201724H -
|
| 12. |
VOE11997843
|
[1] |
Plug
|
|
| 13. |
VOE11988634
|
[1] |
Washer
|
|
| 14. |
VOE11714691
|
[4] |
Nozzle
|
|
| 15. |
VOE11997816
|
[1] |
Dowel
|
|
| 16. |
VOE11997817
|
[4] |
Valve
|
|
| 17. |
VOE11997818
|
[1] |
Ball
|
|
| 18. |
VOE11997819
|
[1] |
Spring
|
|
| 19. |
VOE11997820
|
[1] |
Retainer
|
|
| 20. |
VOE11700781
|
[1] |
Cover
|
|
| 21. |
VOE11998009
|
[1] |
Gasket
|
|
| 22. |
VOE11998031
|
[4] |
Screw
|
|
| 23. |
VOE968147
|
[1] |
Plug
|
|
| 24. |
VOE483645
|
[1] |
Plug
|
|
| 25. |
VOE11998999
|
[1] |
Cover
|
ENG - U176356H
|
| 26. |
VOE6212971
|
[1] |
Sealing ring
|
|
| |
VOE11709507
|
[1] |
Crankshaft seal
|
ENG U176357H -
|
| |
VOE11709508
|
[1] |
Wear sleeve
|
ENG U176357H -
|
| 27. |
VOE11706327
|
[1] |
Gasket
|
|
| 28. |
VOE480219
|
[2] |
Pin
|
|
| 29. |
VOE13946173
|
[12] |
Screw
|
|
| 30. |
VOE11997812
|
[2] |
Screw
|
|
| 31. |
VOE3976749
|
[1] |
Plug
|
|
| 32. |
VOE11997808
|
[1] |
Plug
|
|
| 33. |
VOE7016325
|
[1] |
Plug
|
|
| 34. |
VOE482291
|
[2] |
Plug
|
|
| 35. |
VOE11988321
|
[1] |
Shaft
|
|
