| 1. | 201-318 | [1] | ELBOW,45°, 1 7/16"-12 x 1 5/16"-12. Adj, ORFS | CASIncl. Ref 2, 3; At Control Valve Superseded by part number: 9846885 |
| 2. | 237-6016 | [1] | O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186238, 167268 |
| 3. | 238-6021 | [1] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 87473574 |
| 4. | 87567939 | [1] | HOSE ASSY. | BUR1210 mm (47 - 11/16 in); Control Valve to Therm Bypass |
| 5. | 201-339 | [1] | ELBOW,90º, 1 7/16"-12 x 1 7/16"-12 Fem Sw ORFS | CASIncl Ref 6 |
| 8. | 87578785 | [1] | BY-PASS VALVE | BURIncl Ref 9 |
| 9. | 9824050 | [3] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | WINO-Ring Face Seal End Superseded by part number: 87473574 |
| 13. | 201-355 | [1] | ELBOW,1-3/16" - 12 ORFS x 1-5/16" - 12 ORB | CASIncl. Ref 14, 15 Superseded by part number: 87326965 |
| 15. | 238-6018 | [1] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9991976 |
| 16. | 87579285 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1750.00 mm, SAE 100R17 | BURTank Filter to Thermo Bypass |
| 20. | 87667602 | [1] | HOSE ASSY. | BUR1400 mm (55 - 1/8 in); Thermo, Serial Range: Bypass-Cooler |
| 21. | 201-418 | [2] | TEE,1-7/16" - 12 ORFS x 1-7/16" - 12 ORFS x 1-7/16" - 12 ORFS | CASIncl. Ref 22; If Used |
| 24. | 87668664 | [1] | HOSE ASSY. | BUR1075 mm (42 - 3/8 in);, Serial Range: Bypass-Cooler |
| 25. | 87738634 | [2] | HOSE ASSY. | BURHOSE ASSY., 967mm (38 - 1/8 in); Replaces 87378347, HOSE ASSY., 787mm (31 in); Cooler Extension, Used On Some Models |
| 28. | 87301688 | [2] | CLAMP,41.2mm, Coat, P Type | GI |
| 31. | 86624176 | [2] | WASHER,11mm ID x 20mm OD x 2mm Thk | FOR Superseded by part number: 14496621 |
| 33. | 614-10016 | [2] | BOLT,Hex, M10 x 1.5 x 16mm, Cl 8.8, Full Thd | CAS Superseded by part number: 300383 |
| 36. | 87331818 | [1] | FILTER ASSY | BURHydraulic Oil; See Figure 06-08 |
| 37. | 614-10020 | [4] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43138 |
| 38. | 86625251 | [6] | WASHER,10.5mm ID x 18mm OD x 1.6mm Thk | FAR |
| 39. | 201-105 | [1] | HYD CONNECTOR,1 7/16"-12 ORFS x 1 5/16"-12 ORB | IHIncl. Ref 40, 41 Superseded by part number: 9824055 |
| 42. | 201-393 | [1] | ELBOW,90º, 1 7/16"-12 Adj x 1 7/16"-12 Fem Sw, ORFS | BRRIncl. Ref 43, 44 |
| 46. | 87585367 | [1] | BRACKET | BURW/ Check Tee Mount |
| 47. | 87590350 | [1] | BRACKET | BURCheck Valve Mount |
| 48. | 627-10020 | [2] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd | CAS Superseded by part number: 11106031 |
| 50. | 627-8016 | [2] | BOLT,Hex, M8 x 1.25 x 16mm, Cl 10.9, Full Thd | CAS Superseded by part number: 16043231 |
| 51. | 895-11008 | [2] | WASHER,M8 x 16 x 1.6 | CAS Superseded by part number: 86624184 |
