| 1. | 87658573 | [1] | CONTROL VALVE | BURFour Spool Control Valve; See Figure 08-18 |
| 2. | 201-128 | [2] | HYD CONNECTOR,13/16"-16 ORFS x 1 1/16"-12 ORB | CASIncl. 3, 4 |
| 3. | 237-6012 | [2] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186120, 167266, 79051113 |
| 4. | 238-6014 | [2] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9992298 |
| 5. | 87578208 | [1] | HOSE ASSY. | BURHose Assy, Ripper; Lower Port at Valve / Upper at Bulkhead Tee |
| 5A. | 87578210 | [1] | HOSE ASSY. | BURHose Assy, Ripper; Upper Port at Valve / Lower at Bulkhead Tee |
| 6. | 85802820 | [1] | CHECK VALVE | IMOPilot Operated, Single Acting |
| 7. | 201-101 | [4] | HYD CONNECTOR,11/16"-16 ORFS x 9/16"-18 ORB | CASIncl Ref 7A, 7B Superseded by part number: 9993143 |
| 7A. | 237-6006 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | CASBoss End Superseded by part number: 9617873 |
| 7B. | 238-6012 | [1] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9993141 |
| 8. | L302731 | [1] | CLAMP | CASCLAMP |
| 9. | 614-12045 | [1] | BOLT,Hex, M12 x 1.75 x 45mm, Cl 8.8, Full Thd | CASIf Used Superseded by part number: 9628065 |
| 10. | 896-11012 | [1] | WASHER,13.5mm ID x 24mm OD x 3mm Thk | CASIf Used Superseded by part number: 86625255 |
| 11. | 412126 | [1] | NUT,M12 x 1.75 | ZEDIf Used |
| 12. | 895-11008 | [4] | WASHER,M8 x 16 x 1.6 | CAS Superseded by part number: 86624184 |
| 13. | 43130 | [2] | BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8 | NH |
| 14. | 829-1408 | [2] | NUT,Hex, M8 x 1.25, Cl 10.9 | CAS Superseded by part number: 43362, 87778059 |
| 15. | 87676109 | [2] | HOSE ASSY. | BURHose Assy, Ripper |
