纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (08-16) - VALVE ASSY, THREE SPOOL - SPOOL New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
821 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87658572 | [1] | CONTROL VALVE | BURVALVE CONTROL, Three Spool Control Valve, Incl. Ref 1 - 27; Also See Figures 08-15, 08-17 |
| 1. | 87713183 | [1] | SPOOL | BURAngle Spool; Also See Figure 08-17 |
| 2. | 87713176 | [1] | SPOOL | BURLift Spool |
| 3. | 87713172 | [1] | SPOOL | BURTilt Spool |
| 4. | 87516620 | [2] | RETAINER | BURRETAINER |
| 5. | 87516617 | [5] | SPRING | BURSPRING |
| 6. | 8604582 | [3] | RETAINER | FAR |
| 7. | 87311985 | [1] | SPRING | FAR |
| 8. | 87516632 | [1] | COVER | BURBlock Cover |
| 9. | 87518268 | [5] | SCREW,M5 x 80mm, Gr 8.8 | BURM5 x 80 Screw |
| 10. | 87516634 | [3] | PRESSURE RELIEF VALVE | BURPressure Reducing Valve, FTDRE2; For Service Of External Seals, Order 87516646 Seal Kit; Order 87516645 For Filter |
| . . | 87516645 | [3] | FILTER | LECService |
| . . | 87516646 | [3] | SEAL KIT | BURSeal Kit; Includes (3) O-Rings; Also Includes (2) Backup Rings Not Used In This Application Superseded by part number: 84483008 |
| 11. | 87516635 | [1] | CARTRIDGE | LECPressure Reducing Valve, FTDRE4; For Service Of External Seals, Order 87516646 Seal Kit; Order 87516645 For Filter |
| 12. | 87516612 | [2] | PLUG | BURM22 x 1.5 Plug |
| 13. | 87516611 | [2] | SPOOL | BURCompensator Spool |
| 14. | 87311986 | [1] | RING | FAR |
| 15. | 87311984 | [2] | RETAINER | FARRETAINER |
| 16. | 87516587 | [1] | COVER | BURCover, Pilot, Lift |
| 17. | 864-5060 | [2] | HEX SOC SCREW,M5 x 60mm, Cl 8.8 | V Superseded by part number: 14301521 |
| 18. | 87516585 | [1] | COVER | BURCover, Pilot, Tilt |
| 19. | 864-5055 | [2] | HEX SOC SCREW,M5 x 55mm, Cl 8.8 | FARM5 x 55 Socket Head Screw Superseded by part number: 87657975 |
| 21. | 87516638 | [1] | SEAL KIT | BURValve Block Seal Kit; Includes (18) O-Rings; See Figure 08-15 For Additional O-Ring Locations Superseded by part number: 8604575 |
