纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (09-01B) - FRAME, LIFT - TIE RODS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
531 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 76089483 | [1] | TIE-ROD | LECASSY. Incl. Refs. 1, 1A Superseded by part number: 76066166 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTie-Rod |
| 1A. | 8270124 | [1] | BUSHING,50.19mm ID x 62mm OD x 60mm L | LEC |
| . . | 76089484 | [1] | TIE-ROD | LECASSY. Incl. Refs. 2 - 2E Superseded by part number: 76066162 |
| 2A. | 76003076 | [1] | EYELET | LEC |
| 2B. | 11113431 | [2] | SCREW,Hex, M12 x 60mm, Cl 10.9 | LEC Superseded by part number: 43263 |
| 2C. | 11702921 | [2] | NUT,M12, Cl 10 | LEC Superseded by part number: 17038425 |
| 2D. | 14496731 | [2] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| . . | 76089480 | [1] | TIE-ROD | LECASSY. Incl. Refs. 3 - 3E Superseded by part number: 79081632 |
| 3. | 8295620 | [1] | BUSHING,60.2mm ID x 72mm OD x 45mm L | LEC |
| 3A. | 79081631 | [1] | SLEEVE | LECTie-Rod |
| 3B. | 8295634 | [1] | STEP BOLT | LEC |
| 3C. | 14496931 | [1] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: 86625266 |
| 3D. | 8293408 | [1] | SEAL,59.95mm ID x 75.05mm OD x 7.5mm Thk | LEC |
