凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (15.04[01]) - ROLL WRAP Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
604 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84024746
|
[1] |
SUPPORT
|
PLO
|
| 2. |
80378245
|
[4] |
WASHER
|
ZED
12MM Superseded by part number: 378245
|
| 3. |
84017216
|
[1] |
PIN,12.7mm OD x 64.5mm L
|
ZED
|
| 4. |
80130003
|
[4] |
COTTER PIN
|
ZED
Superseded by part number: 130003
|
| 5. |
89843435
|
[1] |
ACTUATOR
|
PLO
Superseded by part number: 9843435
|
| . . |
9843435R
|
[1] |
REMAN-ELECTRIC ACTUATOR
|
NH
RBX341 (9/02-), RBX341 SILAGE PACK (3/03-), Reman for New P/N 89843435
|
| . . |
9843435C
|
[1] |
CORE-ELECTRIC ACTUATOR
|
NH
Return Number
|
| 6. |
80378244
|
[2] |
LOCK WASHER
|
ZED
11MM Superseded by part number: 378244
|
| 7. |
80120109
|
[2] |
SCREW
|
ZED
M10x20 Superseded by part number: 43138
|
| 8. |
84056958
|
[1] |
COVER PLATE
|
PLO
|
| 9. |
83981963
|
[1] |
SNAP RING,M8 x 0.66mm Thk
|
ZED
|
| 10. |
84024794
|
[1] |
BUSHING
|
NH
|
| 11. |
84024806
|
[1] |
SPACER
|
PA
|
| 12. |
84056960
|
[1] |
SUPPORT
|
PA
|
| 13. |
84056956
|
[1] |
PIN
|
PLO
|
| 14. |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
|
| 15. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 16. |
16043224
|
[2] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
|
| 17. |
84056957
|
[2] |
CLAMP
|
PA
|
