凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (15.05[01]) - ROLL WRAP Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
360 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84078689
|
[1] |
LEVER
|
PLO
|
| 2. |
80120070
|
[1] |
SCREW
|
ZED
M10x60 Superseded by part number: 120070
|
| 3. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 4. |
84024782
|
[1] |
NUT
|
PLO
|
| 5. |
80378244
|
[1] |
LOCK WASHER
|
ZED
10MM Superseded by part number: 378244
|
| 6. |
80170025
|
[1] |
KEY
|
ZED
Superseded by part number: 170025
|
| 7. |
84024601
|
[1] |
SPRING
|
PA
Superseded by part number: 87652453
|
| 8. |
89838295
|
[1] |
BOLT
|
ZED
Superseded by part number: 9838295
|
| 9. |
80140045
|
[1] |
WASHER
|
ZED
Superseded by part number: 140045
|
