纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (09-09) - MOUNTING - FUEL TANK/HYDRAULIC RESERVOIR & FRAME, UPPER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
505 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87671486 | [1] | Frame/A; Tankframe & Tanks; Not Serviced As A Components; Includes 1, 2 | |
| 1. | 87695168 | [1] | TANK, HYDRAULIC OIL | BURTank, Hydraulic; Complete; See Figure 08-01 |
| 2. | 87695179 | [1] | FUEL TANK | BURTank, Fuel; Complete; See Figure 03-01 |
| 3. | 87690481 | [8] | BOLT,Hex, M22 x 70mm, Cl 10.9 | BHBBolt |
| 4. | 896-11022 | [8] | WASHER,24mm ID x 44mm OD x 4mm Thk | CAS Superseded by part number: 76088905 |
| 5. | 87447306 | [2] | SQUARE NUT | CASCage; Replaces L116823 |
| 6. | 336371A1 | [2] | PIN | CAS |
| 7. | 814-16060 | [12] | BOLT,Hex, M16 x 2 x 60mm, Cl 8.8 | CAS Superseded by part number: 323866 |
| 8. | D44330 | [12] | SHIM,.031" Thk | CAS |
| 9. | 896-11016 | [3] | WASHER,17.5mm ID x 30mm OD x 4mm Thk | IH Superseded by part number: 86625266 |
| 10. | 896-11012 | [2] | WASHER,13.5mm ID x 24mm OD x 3mm Thk | CAS Superseded by part number: 86625255 |
| 11. | 87671488 | [1] | COVER PLATE | BURCover, Rear |
| 12. | 614-12045 | [2] | BOLT,Hex, M12 x 1.75 x 45mm, Cl 8.8, Full Thd | CAS Superseded by part number: 9628065 |
| 13. | 87653200 | [1] | FRAME | BUR |
| 14. | 345-148 | [12] | SEALANT, THREAD | CURAdhesive Thread |
| 15. | 87587743 | [1] | SPACER | BUR |
| 16. | 87440363 | [12] | SPACER | CAS |
