| 1. | 87718961 | [1] | HOOD | BURPlate, Painted; If Used |
| 2. | 87608135 | [1] | HOOD | BURDOOR; Used With 87718961 Hood; If used |
| 3. | 76079374 | [1] | LATCH | LECUsed With 87608135, Hood Door; If used |
| 4. | 614-8025 | [4] | BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43127 |
| 5. | 86625263 | [4] | WASHER,9mm ID x 20mm OD x 1.6mm Thk | ZED |
| 6. | 14508287 | [4] | PLUG | LEC |
| 7. | 627-12040 | [2] | BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd | CASUsed at the rear of the Hood Superseded by part number: 337563 |
| 8. | 893-11012 | [2] | LOCK WASHER,Ext Tooth, M12 | CASUsed at the rear of the hood Superseded by part number: 83925303 |
| 9. | 79032003 | [2] | BUSHING | LECSPACER, Used at the rear of the Hood |
| 10. | 79109730 | [4] | RUBBER BUSHING | LECUsed at the front of the Hood |
| 11. | 79109732 | [4] | WASHER,M12.5 x 43 x 3 Thk | LECUsed at the front of the Hood |
| 12. | 79109731 | [2] | SPACER | LECUsed at the front of the Hood |
| 13. | 627-12080 | [2] | BOLT,Hex, M12 x 1.75 x 80mm, Cl 10.9, Full Thd | CASUsed at the front of the Hood Superseded by part number: 87015764 |
| 14. | 87699541 | [1] | WALL | BURFIREWALL, Painted |
| 15. | 86629891 | [4] | WASHER,19.8mm ID x 41.5mm OD x 5mm Thk | WIC |
| 16. | 16162431 | [4] | BOLT,Hex, M18 x 2.5 x 45mm, Cl 10.9, Full Thd | MKT Superseded by part number: 16162434 |
| 17. | 87662839 | [1] | PLATE | BURRight Hand |
| 18. | 87662838 | [1] | PLATE | BURLeft Hand; Not Illustrated |
| 19. | 627-8020 | [6] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43233 |
| 21. | 87728839 | [6] | SHIM | BHBSHIM, Door Latch |
| 22. | 425-115 | [4] | NUT,5/16"-24, G5 | CAS Superseded by part number: 86629539 |
| 23. | 87330642 | [4] | BUMPER | BUR |
| 24. | 87662800 | [1] | SEAL | BURSEAL, Cowl Foam |
| 25. | 87751240 | [1] | HOOD | BHBHood; If used |
| 26. | 87751239 | [1] | COVER | BHBHood Door, Used With 87751240 Hood; If Used |
| 27. | 356924A3 | [1] | LATCH | CASUsed With 87751239 Hood Door; If Used |
| 28. | 87440322 | [2] | HINGE | BURUsed With 87751239 Hood Door; If Used |
| 29. | 896-11006 | [8] | WASHER,6.6mm ID x 12.5mm OD x 2mm Thk | IH Superseded by part number: 87778338, 86588450 |
| 30. | 844-6030 | [2] | BOLT,Hvy Hex, M6 x 30mm, Cl 8.8 | CAS Superseded by part number: 86511839 |
| 31. | 832-10406 | [2] | NUT,M6 x 1, Cl 8 | CAS |
