纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (09-12B) - NOISE CONTROL New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
534 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87749425 | [1] | INSULATING PANEL | BURPANEL, INSULATING; LH Door Upper; Replaces 87727731 |
| 2. | 87727732 | [1] | INSULATING PANEL | BURLH Door Lower |
| 3. | 87727733 | [1] | INSULATING PANEL | BURRH Door Lower |
| 4. | 87749426 | [1] | INSULATING PANEL | BURPANEL, INSULATING; RH Door Upper; Replaces 87727734 |
| 5. | 87749427 | [1] | INSULATING PANEL | BURPANEL, INSULATING; LH Side Shield; Replaces 87727735 |
| 6. | 87749428 | [1] | INSULATING PANEL | BURPANEL, INSULATING; RH Side Sheild; Replaces 87727736 Superseded by part number: 87758152, 87758151 |
| 7. | 87727737 | [2] | INSULATING PANEL | BURCenter Rops Superseded by part number: 87758156, 87758155 |
| 8. | 87727738 | [1] | INSULATING PANEL | BURRH Rops |
| 9. | 87727739 | [1] | INSULATING PANEL | BURLH Rops |
| 10. | 87727740 | [1] | INSULATING PANEL | BURFront Rops Superseded by part number: 87758154, 87758153 |
| 11. | 87727741 | [1] | INSULATING PANEL | BURRear Rops |
