神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (06-001) - PUMP - WATER (FITTING PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
887 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG2100896101 | [1] | PUMP | KOBWater |
| 2. | VG0093111210 | [1] | PLUG TAPER | PLUG TAPER |
| 3. | VG2100996000 | [1] | DRIVEN GEAR | KOBWATER PUMP |
| 4. | VG0891284210 | [1] | NUT | KOBLOCK |
| 5. | VG0891514210 | [1] | WASHER | KOBWASHER SPRING Superseded by part number: VG089151421A |
| 6. | VG2101496000 | [1] | GASKET PUMP | GASKET PUMP |
| 7. | VG0812083028 | [1] | BOLT W/ WASHER (FOR A1) | BOLT W/ WASHER (FOR A1) |
| 7. | VG0812083010 | [1] | BOLT (FOR A1) | BOLT (FOR A1) |
| 7. | VG0812082528 | [1] | BOLT W/WASHER (FOR A2) | BOLT W/WASHER (FOR A2) |
| 8. | VG0112100134 | [2] | BOLT W/WASHER (FOR A1) | BOLT W/WASHER (FOR A1) |
| 9. | VG0112100154 | [1] | SPECIAL WASHER | KOB(FOR A2) |
| 10. | VG0891513810 | [1] | WASHER SPRING | WASHER SPRING |
| 11. | VG2101296004 | [1] | PUMP | KOB(FOR A1) |
| 11. | VG2101296001 | [1] | DUCT | KOB(FOR A2) |
| 12. | VG2101596000 | [1] | GASKET FLANGE | GASKET FLANGE |
