| 1. | 87668142 | [1] | Brush Guard; Bolted Assy; Incl. 16 -23 | |
| 2. | 436119A4 | [2] | MOUNTING PLATE | BUR |
| 3. | 627-20055 | [2] | BOLT,Hex, M20 x 2.5 x 55mm, Cl 10.9, Full Thd | CAS Superseded by part number: 190003809441 |
| 4. | 496-41081 | [2] | WASHER,13/16" x 1 3/4" x .219", HDN | CAS Superseded by part number: 87326714 |
| 6. | 627-16035 | [4] | BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd | CASUse with Loctite No. 243 Superseded by part number: 86529976 |
| . . | 345-199 | [1] | ADHESIVE | CASThread, Loctite No. 243, 1 ml |
| 7. | 896-11016 | [4] | WASHER,17.5mm ID x 30mm OD x 4mm Thk | IH Superseded by part number: 86625266 |
| 8. | 87616258 | [1] | BRACKET | BURBracket RH |
| 8. | 87616257 | [1] | BRACKET | BURBracket LH |
| 9. | R40721 | [4] | GROMMET | CASInsulator |
| 10. | R40954 | [2] | BUSHING | CAS |
| 11. | 827-16100 | [2] | BOLT,Hex, M16 x 2 x 100mm, Cl 10.9 | CAS Superseded by part number: 86541970 |
| 12. | 832-10416 | [2] | NUT,M16 x 2, Cl 8 | CAS Superseded by part number: 412066 |
| 13. | 87563129 | [6] | SCREW,Hex, M16 x 50mm, Cl 8.8 | BHB |
| 14. | 86639326 | [6] | WASHER,17.3mm ID x 34.5mm OD x 5mm Thk | FAR |
| 16. | 87668145 | [1] | TUBE,802 mm L | BURTUBE, Brush Guard; Right Hand |
| 17. | 87668147 | [1] | TUBE,539.82 mm L | BURTUBE, Brush Guard; Cross |
| 18. | 87668143 | [1] | TUBE,802 mm L | BURTUBE, Brush Guard; Left Hand |
| 19. | 814-12060 | [2] | BOLT,Hex, M12 x 1.75 x 60mm, Cl 8.8 | CAS Superseded by part number: 9706693 |
| 20. | 832-10412 | [2] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 21. | 895-11012 | [2] | WASHER,13.5mm ID x 24mm OD x 2.5mm Thk | CAS |
| 22. | D25022 | [2] | WASHER | CASPin Link Pocket |
| 23. | R29799 | [2] | SHOCK ABSORBER | CASIsolator |
