纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (09-28) - CAB - CONSOLES, SIDE AND REAR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
883 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87372082 | [1] | CONSOLE | BURRight-Hand |
| 2. | 87372055 | [1] | CONSOLE | BURLeft-Hand |
| 3. | 76067249 | [2] | SHIELD | LECSeal, Lockout/Parking Brake Levers |
| 4. | 76079036 | [2] | VENT | LECLouver |
| 5. | 87372034 | [1] | COVER | BHBLeft-Hand Rear HVAC |
| 6. | 87372036 | [1] | COVER | BHBRight-Hand Rear HVAC |
| 7. | 87372052 | [1] | COVER | BHBCenter Rear HVAC |
| 8. | 87530504 | [1] | CAP | BHBController |
