纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (09-31) - CAB - MIRROR, DOME LAMP, ANTENNA AND RADIO MOUNT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
229 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 197745A1 | [1] | ANTENNA | CASRadio;Includes Flat Washer and Nut Which Are Not Serviced Separately |
| 2. | 198960A1 | [1] | ANTENNA | CASRadio Antenna Ground Superseded by part number: 197745A1 |
| 3. | 394799A1 | [1] | LIGHT ASSY.,24 /28V, W | CASInterior, Dome Lamp; Incl. Ref 4 |
| 4. | 395185A1 | [2] | BULB,24V, 10W | CAS24V, 10W Bulb |
| 5. | 76067706 | [1] | REAR VIEW MIRROR | LECInterior |
| 6. | 87444309 | [1] | BRACKET | BURMirror Support Bracket |
| 7. | 614-8025 | [2] | BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43127 |
| 8. | 895-11008 | [2] | WASHER,M8 x 16 x 1.6 | CAS Superseded by part number: 86624184 |
| 9. | 892-11008 | [2] | LOCK WASHER,M8 | IH Superseded by part number: 72187304, 83990583 |
| 10. | 87517929 | [1] | BRACKET | BURRadio Mount |
| 11. | 1535219C1 | [1] | COVER | IHRadio Opening |
