神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (03-012) - COMPERRSOR - AIR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
460 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-47. | VG1450196008 | [1] | INSULATING BLOCK COMPRESSOR-AIR (FOR A1) | INSULATING BLOCK COMPRESSOR-AIR (FOR A1) |
| 1-47. | VG1450196010 | [1] | COMPRESSOR-AIR (FOR A2) | |
| 1-47. | VG1450196011 | [1] | COMPRESSOR-AIR (FOR A3) | |
| 1. | VG1450699013 | [1] | CASE-CRANK (FOR A2,A3), Start Year: 01-JUN-83 | |
| 1. | VG1450699009 | [1] | CASE-CRANK (FOR A2,A3) | |
| 2. | VG1451399110 | [1] | HOLDER-BEARING (FOR A2,A3), Start Year: 01-JUN-83 | |
| 2. | VG1451399102 | [1] | HOLDER-BEARING (FOR A2,A3) | |
| 3. | VG2116299000 | [1] | BEARING-BALL | |
| 4. | VG1451190008 | [1] | BEARING BEARING-BALL | BEARING BEARING-BALL |
| 5. | VG1450999014 | [1] | SHAFT-CRANK (FOR A1,A2) | |
| 5. | VG1450999019 | [1] | CRANKSHAFT | KOBSHAFT-CRANK (FOR A3) |
| 6. | VG1451499016 | [1] | PACKING | KOBPACKING (FOR A2,A3), Start Year: 01-JUN-83 |
| 6. | VG1451499013 | [1] | PACKING | KOBPACKING (FOR A2,A3) |
| 7. | VG0092652200 | [1] | KEY | KOBKEY-WOODRUFF (FOR A1) |
| 7. | VG1463690002 | [1] | KEY-WOODRUFF (FOR A2,A3) | |
| 8-12. | VG1451699006 | [1] | ROD ASSY-CONNECTOR | |
| 9. | VG1451999003 | [2] | SET OF STD MAIN BRGS | KOBMETAL |
| 10. | VG1452199002 | [2] | BOLT (FOR A1) | |
| 10. | VG14521Z9001 | [2] | SCREW | KOBBOLT (FOR A2,A3) |
| 11. | VG1450599000 | [2] | NUT (FOR A1) | |
| 11. | VG1450599001 | [2] | NUT (FOR A2,A3) | |
| 12. | VG14522Z9000 | [2] | LOCK WASHER | KOBWASHER |
| 13. | VG1452899009 | [1] | PISTON | KOBPISTON |
| 14. | VG1453296000 | [1] | PIN PIN | PIN PIN |
| 15. | VG0811102520 | [8] | BOLT, M10X25 | |
| 18. | VG1452999007 | [1] | SET OF RINGS | KOBRING KIT-PISTON |
| 20. | VG1451599006 | [1] | OIL SEAL | KOBSEAL-OIL |
| 21. | VG0891514000 | [8] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| 24. | VG1459296000 | [2] | SCREW | KOBSCREW-MACHINE. |
| 26. | VG1453496000 | [2] | PISTON RING SET | KOBCLIP |
| 28. | VG1451490003 | [1] | O-RING | KOBO RING (FOR A1) |
| 28. | VG1451499015 | [1] | O-RING O RING (FOR A2,A3) | O-RING O RING (FOR A2,A3) |
| 29. | VG1453599009 | [1] | LINER, ENGINE CYLIND | KOBLINER-CYLINDER (FOR A1) |
| 29. | VG1453599013 | [1] | LINER, ENGINE CYLIND | KOBLINER-CYLINDER (FOR A2,A3) |
| 30. | VG1451499011 | [1] | O-RING | KOBO RING |
| 31-47. | VG1454099112 | [1] | CYLINDER HEAD | KOBHEAD ASSY-CYLINDER |
| 31. | VG1454899013 | [1] | CYLINDER HEAD | KOBHEAD-CYLINDER |
| 32-36. | VG1457099126 | [1] | VALVE | KOBVALVE KIT-SUCTION |
| 32. | VG1457799001 | [1] | HOLDER, INJECTOR NOZ | KOBHOLDER-VALVE |
| 33. | VG1456896000 | [1] | SPRING | KOBSPRING-VALVE |
| 34. | VG1457096000 | [1] | VALVE | KOBVALVE-SUCTION |
| 35. | VG1457296000 | [1] | PACKING | KOBPACKING-VALVE |
| 36. | VG1457196000 | [1] | VALVE SEAT | KOBSEAT-VALVE |
| 37-39. | VG1455299000 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE VALVE ASSY-UNLOADER Superseded by part number: 1455299000 |
| 38. | VG1455690001 | [1] | SPRING | KOBSPRING-VALVE Superseded by part number: 1455690001 |
| 39. | VG1453390001 | [1] | CLIP CLIP (FOR A1) | CLIP CLIP (FOR A1) |
| 39. | VG1453399000 | [1] | CLIP (FOR A2,A3) | |
| 40-45. | VG1456999129 | [1] | VALVE | KOBVALVE KIT-DELIVERY |
| 40. | VG1455599009 | [1] | HOLDER ASSY | |
| 41. | VG1455096000 | [1] | HYDRAULIC VALVE | KOBSPRING-VALVE |
| 42. | VG1455196000 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE VALVE-DELIVERY |
| 43. | VG1455399003 | [1] | VALVE SEAT | KOBSEAT-VALVE |
| 44. | VG1458299005 | [1] | O-RING | KOBO RING |
| 45. | VG14552Z9000 | [1] | O-RING | KOBO RING |
| 46. | VG1455999003 | [1] | CONNECTOR CONNECTOR | CONNECTOR CONNECTOR |
| 47. | VG0996161800 | [1] | PACKING | |
