神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (04-001[01]) - PUMP-OIL, (FITTING PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
761 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG1501096016 | [1] | PUMP | KOBPUMP ASSY-OIL (INNER PARTS E150D) (FOR A1)(8210) |
| 1. | VG1501096009 | [1] | PUMP ASSY-OIL(INNER PARTS E150C) (FOR A1) | |
| 1. | VG1501096006 | [1] | PUMP | KOBPUMP ASSY-OIL (INNER PARTS E150B (FOR B2) |
| 2. | VG0112100044 | [4] | BOLT BOLT,W/WASHER | BOLT BOLT,W/WASHER |
| 3. | VG1506896004 | [1] | INJECTION PIPE | KOBPIPE-OUTLET (FOR A1) |
| 3. | VG1506896007 | [1] | PIPE-OUTLET (FOR B2) | |
| 4. | VG1506690003 | [1] | GASKET | KOBGASKET (FOR B2) Superseded by part number: VG15066NB000 |
| 5. | VG0812082528 | [2] | BOLT BOLT,W/WASHER (FOR B2) | BOLT BOLT,W/WASHER (FOR B2) |
| 6. | VG1307395000 | [2] | RUBBER RING | KOBO RING (FOR B2) |
| 7. | VG3252596000 | [1] | BAFFLE-OIL (FOR B2) | |
| 8. | VG0812102528 | [2] | BOLT BOLT,W/WASHER (FOR B2) | BOLT BOLT,W/WASHER (FOR B2) |
| 9. | VG9101990002 | [2] | WASHER-PLAIN (FOR B2) | |
| 10. | VG1506496073 | [1] | PIPE ASSY (FOR B2) | |
| 11. | VG1307395001 | [2] | RUBBER RING | KOBO RING (FOR B2) |
| 12. | VG0812081628 | [2] | BOLT,W/WASHER (FOR B2) | |
| 13. | VG0811401610 | [1] | SCREW | KOBBOLT (FOR B2) |
| 14. | VG0891114010 | [1] | NUT (FOR B2) | NUT (FOR B2) |
| 15. | VG0891514010 | [1] | WASHER WASHER-SPRING (FOR B2) | WASHER WASHER-SPRING (FOR B2) |
| 16. | VG9101990002 | [1] | WASHER-PLAIN (FOR B2) | |
| 17. | VG0112100054 | [2] | BOLT BOLT,W/WASHER (FOR B2) | BOLT BOLT,W/WASHER (FOR B2) |
| 18. | VG0812404010 | [2] | BOLT (FOR B2) | |
| 19. | VG0891514010 | [2] | WASHER WASHER-SPRING (FOR B2) | WASHER WASHER-SPRING (FOR B2) |
| 20. | VG0891124010 | [2] | NUT | KOBNUT (FOR B2) |
