| 1. |
84446957
|
[1] |
WIRE HARNESS
|
PLO
(2, 3, 4, 8)
|
| 2. |
80426199
|
[20] |
TERMINAL
|
ZED
Superseded by part number: 426199
|
| 3. |
80430026
|
[8] |
TERMINAL
|
ZED
Superseded by part number: 430026
|
| 4. |
190067
|
[4] |
RUBBER BUSHING
|
ZED
Superseded by part number: 80190067
|
| 5. |
80398224
|
[1] |
POWER SOCKET
|
ZED
Superseded by part number: 83959716
|
| 6. |
84447454
|
[1] |
WIRE HARNESS
|
PLO
(2, 5, 8)
|
| 7. |
80334591
|
[2] |
TERMINAL
|
ZED
|
| 8. |
80398225
|
[2] |
WIRE CONNECTOR
|
ZED
Superseded by part number: 398225
|
| 9. |
80301572
|
[3] |
SCREW
|
ZED
M4x35 Superseded by part number: 86585707
|
| 10. |
80140013
|
[3] |
WASHER
|
ZED
4MM Superseded by part number: 89824840
|
| 11. |
80322355
|
[7] |
WASHER
|
ZED
4MM Superseded by part number: 322355
|
| 12. |
80100012
|
[7] |
NUT
|
ZED
M4 Superseded by part number: 57121
|
| 13. |
89508568
|
[6] |
HYD TUBE
|
ZED
|
| 14. |
89503931
|
[4] |
CLAMP
|
ZED
Superseded by part number: 84818444
|
| 15. |
80398877
|
[4] |
BULB
|
ZED
Superseded by part number: 14148190
|
| 16. |
80418870
|
[2] |
BULB
|
ZED
Superseded by part number: 14149590
|
| 17. |
86508568
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 18. |
80322357
|
[4] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 19. |
15896221
|
[4] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 20. |
84037090
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
RH
|
| 20. |
84037093
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
LH
|
| 21. |
80323597
|
[1] |
STRAP
|
ZED
Superseded by part number: 14560287
|
| 22. |
80746294
|
[2] |
LAMP REFLECTOR
|
ZED
|
| 23. |
86511042
|
[4] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 24. |
84446946
|
[1] |
SUPPORT
|
PLO
|
