纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (05-07A) - TRACK GUARDS & GUIDES (XLT/LGP MODELS) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
596 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87599548 | [4] | GUARD | BURGUARD, Center |
| 2. | 87599551 | [2] | GUIDE | BURRear, Right Hand Outer, Left Hand Inner |
| 3. | 87599546 | [2] | GUARD | BURCover, Left Hand Inner, Right Hand Outer |
| 4. | 87599544 | [2] | GUIDE | BURRear, Left Hand Outer, Right Hand Inner |
| 5. | 87599545 | [2] | GUARD | BURCover, Left Hand Outer, Right Hand Inner |
| 6. | 1590067 | [12] | BOLT,Hex, M20 x 2.5 x 320mm, Cl 8.8 | BERBOLT, Hex M20 x 320 Cl 8.8 |
| 7. | 86625260 | [60] | WASHER,21.8mm ID x 37.5mm OD x 4mm Thk | FAR |
| 8. | 87558879 | [12] | SPACER | BUR |
| 9. | 9672396 | [12] | NUT | WIN |
| 10. | 604-20045 | [40] | BOLT,Hex, M20 x 45mm, Cl 8.8 | CASBOLT |
| 11. | 604-12030 | [8] | BOLT,Hex, M12 x 30mm, Cl 8.8 | CAS Superseded by part number: 86624975 |
| 12. | D64050 | [8] | WASHER | CASHeat Treated |
| 13. | R43651 | [8] | SPACER | CASSpacer |
| 14. | 86625266 | [12] | WASHER,17.5mm ID x 30mm OD x 4mm Thk | GI |
| 15. | 87563128 | [12] | LOCK BOLT,Hex, M16 x 2 x 35mm, Cl 8.8, Full Thd | BRRBOLT, Locking M16 x35 |
| 16. | 87599547 | [4] | GUIDE | BURCenter Track |
