神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (04-002) - PUMP-OIL, (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
350 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1- 26. | VG1502199013 | [1] | STATOR | KOBROTOR-INNER |
| 3. | VG1502399013 | [1] | STATOR | KOBROTOR-OUTER |
| 4. | VG1501499006 | [1] | COVER ASSY | |
| 5. | VG1501999007 | [4] | DOWEL | |
| 6. | VG1501999006 | [1] | PIN | |
| 7. | VG1502299004 | [1] | SHAFT | KOBSHAFT |
| 8. | VG1503499001 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE VALVE-RELIEF |
| 9. | VG1503599003 | [1] | SPRING | KOBSPRING |
| 10. | VG1503799002 | [1] | SHIM | KOBSHIM |
| 11. | VG1504499006 | [1] | GEAR | |
| 12. | VG1504699004 | [1] | NUT | |
| 13. | VG1504799003 | [1] | WASHER-LOCK | |
| 14. | VG0092651600 | [1] | KEY | KOBKEY-WOODRUFF |
| 15. | VG1503399007 | [5] | BOLT | |
| 16. | VG0891514010 | [5] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| 17. | VG1504899001 | [1] | COVER | |
| 18. | VG1504899000 | [1] | PLATE | |
| 19. | VG1504799004 | [1] | WASHER-LOCK | |
| 20. | VG1504699005 | [1] | NUT | |
| 21. | VG1503799003 | [1] | SHIM | KOBSHIM |
| 22. | VG1502999001 | [1] | KEY | KOBKEY |
| 23. | VG1502999002 | [1] | KEY | KOBKEY |
| 24. | VG1502399012 | [1] | STATOR | KOBROTOR-OUTER |
| 25. | VG1502199012 | [1] | STATOR | KOBROTOR-INNER |
| 26. | VG1501199003 | [1] | CASE ASSY | |
