神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (04-003) - PUMP-OIL, (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
350 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-10. | VG1501096016 | [1] | PUMP | KOBPUMP-OIL |
| 1. | VG1502399200 | [1] | COVER ASSY-GEAR | |
| 2. | VG1502399011 | [1] | GEAR ASSY | |
| 3. | VG1501499005 | [1] | COVER ASSY | |
| 4. | VG1503499001 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE VALVE-OIL RELIEF |
| 5. | VG1503599003 | [1] | SPRING | KOBSPRING-OIL RELIEF |
| 6. | VG1503699003 | [1] | SEAL | KOBSEAT-SPRING |
| 7. | VG1503999000 | [1] | KEY | KOBPIN-SPLIT |
| 8. | VG1503399005 | [3] | BOLT | |
| 9. | VG1503399006 | [1] | BOLT | |
| 10. | VG0891513810 | [4] | WASHER SPRING WASHER-SPRING | WASHER SPRING WASHER-SPRING |
