凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (06.26[01]) - STEERING AND TAIL GATE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
221 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84058011
|
[2] |
MULTIPOLE CONNECTOR,Female, 40 Pole
|
ZED
Superseded by part number: 225414C1
|
| 2. |
84068583
|
[42] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
| 3. |
84437943
|
[1] |
ECU
|
ZED
|
| 4. |
84074631
|
[4] |
CONTACT HOUSING,Female, 2 Pole
|
ZED
Superseded by part number: 87695582
|
| 5. |
84074638
|
[4] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| 6. |
89503929
|
[4] |
CLAMP
|
ZED
Superseded by part number: 84818442
|
| 7. |
84058863
|
[2] |
SENSOR
|
ZED
|
| 8. |
84078760
|
[1] |
SENSOR
|
ZED
|
| 9. |
84446643
|
[1] |
WIRE HARNESS
|
PLO
(1, 2, 4, 5)
|
| 10. |
NS
|
[3] |
NOT SERVICED
|
BAS
|
