凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (06.27[01]) - SATELLITE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
756 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074643
|
[2] |
CONTACT HOUSING,Female, 6 Pole
|
ZED
|
| 2. |
84074641
|
[2] |
WEDGE
|
ZED
Superseded by part number: 87694150
|
| 3. |
84074631
|
[6] |
CONTACT HOUSING,Female, 2 Pole
|
ZED
Superseded by part number: 87695582
|
| 4. |
84074638
|
[6] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| 5. |
84818617
|
[1] |
ELECTRIC CLUTCH
|
PLO
|
| 6. |
84078760
|
[1] |
SENSOR
|
ZED
|
| 7. |
84821040
|
[1] |
SUPPORT
|
PLO
|
| 8. |
89993154
|
[1] |
CLAMP
|
ZED
Superseded by part number: 263117
|
| 9. |
84446694
|
[1] |
WIRE HARNESS
|
PLO
(1 to 4, Serial Range: 10-14)
|
| 10. |
84068583
|
[2] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
| 11. |
84806208
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 12. |
84806312
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
|
| 13. |
84806311
|
[1] |
WIRE CONNECTOR,Female, 8 Pin , 14 - 20 SAE
|
ZED
|
| 14. |
86500036
|
[20] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
|
| 15. |
84058863
|
[3] |
SENSOR
|
ZED
|
| 16. |
84058861
|
[2] |
SENSOR
|
ZED
|
| 17. |
84821042
|
[2] |
SUPPORT
|
PLO
|
| 18. |
89503929
|
[5] |
CLAMP
|
ZED
Superseded by part number: 84818442
|
| 19. |
84446643
|
[1] |
WIRE HARNESS
|
PLO
(1 to 4, 10, 14)
|
| 20. |
NS
|
[2] |
NOT SERVICED
|
BAS
|
