凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (06.28[01]) - ROTARY BEACON AND BASKET Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
245 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074638
|
[2] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| 2. |
84074631
|
[2] |
CONTACT HOUSING,Female, 2 Pole
|
ZED
Superseded by part number: 87695582
|
| 3. |
84074630
|
[1] |
CONTACT HOUSING,Male, 2 Pole
|
ZED
|
| 4. |
80446133
|
[1] |
ELEC CONNECTOR
|
ZED
Superseded by part number: 446133
|
| 5. |
86500166
|
[1] |
ELEC CONNECTOR
|
ZED
Superseded by part number: 225318C1
|
| 6. |
84058863
|
[2] |
SENSOR
|
ZED
|
| 7. |
89993154
|
[2] |
CLAMP
|
ZED
Superseded by part number: 263117
|
| 8. |
89503929
|
[5] |
CLAMP
|
ZED
Superseded by part number: 84818442
|
| 10. |
89513421
|
[1] |
BEACON
|
ZED
Superseded by part number: 9513421
|
| 11. |
89513422
|
[1] |
WIRE CONNECTOR
|
ZED
Superseded by part number: 9513422
|
| 12. |
84073655
|
[1] |
SUPPORT
|
ZED
|
| 13. |
84073092
|
[1] |
WIRE HARNESS
|
ZED
|
| 14. |
89507807
|
[1] |
CLAMP
|
ZED
Superseded by part number: 9507807
|
| 15. |
NS
|
[1] |
NOT SERVICED
|
BAS
|
| 16. |
80322356
|
[1] |
WASHER
|
ZED
5MM Superseded by part number: 322356
|
| 17. |
80043129
|
[2] |
SCREW
|
ZED
M8x40 Superseded by part number: 16044024
|
| 18. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 20. |
80323597
|
[2] |
STRAP
|
ZED
Superseded by part number: 14560287
|
| 22. |
84100298
|
[1] |
FUSE
|
ZED
Superseded by part number: 9811773
|
| 23. |
84000651
|
[1] |
RELAY
|
ZED
Superseded by part number: 86529089
|
| 24. |
84446643
|
[1] |
WIRE HARNESS
|
PLO
(1 to 5, Serial Range: 25-27)
|
| 25. |
86500035
|
[2] |
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
|
GI
Superseded by part number: 87695607
|
| 26. |
86500036
|
[4] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
|
| 27. |
80441166
|
[2] |
TERMINAL
|
ZED
Superseded by part number: 441166
|
| 19. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
