| . . | 87670995 | [1] | BEAM | BUREqualizer; 74 Gauge, Standard Dozer, Extended Long Track (XLT) & Long track (LT) Models, Incl. 1 - 5, 19, 20 |
| . . | 87670994 | [1] | BEAM | BUREqualizer, 84 Gauge Wide Track (WT) or Low Ground Pressure (LGP) Models, Incl. 1 - 5, 19, 20, Not Illustrated Superseded by part number: 84208110 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBeam, Equalizer |
| 2. | D51545 | [2] | BUSHING,63.75mm ID x 76.2mm OD x 38.1mm L | CASCenter |
| 3. | R39286 | [2] | SEAL,63.5mm ID x 76.33mm OD x 7.92mm Thk | CASUse With Ref 3A, 3B |
| 3A. | 345-79 | [1] | ADHESIVE | CASLoctite, No. 609, 1 ml |
| 4. | 87381270 | [2] | SPHERICAL BEARING,60mm ID x 90mm OD x 44mm W | BURBearing |
| 5. | 11062476 | [4] | SNAP RING,M90, Int | TTF Superseded by part number: |
| 6. | 87627809 | [1] | PIN,63.5mm OD x 271mm L | BURCenter |
| 7. | 87538548 | [2] | SCREW | BHBBOLT, Flange Head Locking Bolt, 3/4 x 1-3/4 |
| 9. | T31129 | [2] | BUSHING,19.66mm ID x 31.75mm OD x 17.48mm L | CASBushing |
| 10. | 217-1014 | [1] | ELBOW,90º, 1/8"-27 Female x 1/8"-27 Male | CAS Superseded by part number: 217-20 |
| 11. | 87632908 | [1] | HOSE ASSY. | BUR1643 mm (64 - 11/16 in), Grease; No Longer Used Order R45862 Superseded by part number: 84410662 |
| 11. | R45862 | [1] | HOSE,3.17mm ID x 1041.4mm L, SAE 100R7 | CAS1041 mm (41 in), Grease |
| 12. | 219-8 | [1] | LUBE NIPPLE,1/4"-28 x 1/2" | CAS Superseded by part number: 87414 |
| 13. | F53473 | [1] | LOCK NUT,1/8-27 NPSM | CAS1/8 PT Superseded by part number: 76085536 |
| 14. | 217-429 | [2] | PLUG,Hex Soc, 1/8"-27 NPTF | CASUse with Loctite 592 Superseded by part number: 86637724 |
| 15. | 87542287 | [2] | PIN,60mm OD x 202.05mm L | BUROuter |
| 16. | 87563127 | [2] | BOLT,Hex, M20 x 50mm, Cl 10.9 | BHBBOLT |
| 17. | 86639847 | [2] | WASHER,21.8mm ID x 44.5mm OD x 5mm Thk | RAC |
| 18. | 87652972 | [2] | BUSHING | BURBUSHING |
| 19. | 76043711 | [4] | SEAL,60mm ID x 112.3mm OD x 11.1mm Thk | LECSeal; Included In Equalizer Beam Assy |
| 20. | 11075676 | [4] | SNAP RING,M115, Int | MKTSnap Ring; Included In Equalizer Beam Assy |
