| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87378232 | [1] | PLATE | BURFirewall Plate; Canopy Models |
| 1. | 87568861 | [1] | PLATE | BURFirewall Plate; Cab Models; Not Illustrated |
| 2. | 87378238 | [1] | Brake and Decelerator Pedal Assembly; Not Available As An Assembly, Order Components, See Figure 07-02 | |
| 3. | 614-10025 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8 | CAS Superseded by part number: 11106231 |
| 4. | 896-15010 | [2] | WASHER,11mm ID x 24mm OD x 3mm Thk | CAS Superseded by part number: 86639325 |
| 5. | 87395690 | [1] | PLATE | BURBrake and Decelerator Pedal Cover |
| 6. | 614-10020 | [6] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43138 |
| 8. | 76046804 | [1] | FOOTREST | LEC |
| 9. | 614-10040 | [4] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd | CAS Superseded by part number: 120112 |
| 10. | 892-11010 | [4] | LOCK WASHER,M10 | CAS Superseded by part number: 140028 |
| 12. | 614-10050 | [1] | BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8, Full Thd | CASAdjust for Brake Potentiometer Voltage Superseded by part number: 120113 |
| 13. | 829-1410 | [1] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
