神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (04-012) - FILTER-FUEL, (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
176 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-10. | VG1640096010 | [1] | FUEL FILTER | KOB(NICHIRO MAKE) (FOR A1) |
| 1-10. | VG1640096011 | [1] | ELEMENT FILTER-FUEL (TSUCHIYA MAKE) (FOR A2) | ELEMENT FILTER-FUEL (TSUCHIYA MAKE) (FOR A2) |
| 1-10. | VG1640096019 | [1] | FILTER-FUEL (TSUCH1YA MAKE) (FOR A3) | |
| 1-3. | VG1644499128 | [1] | ELEMENT | KOB(FOR A1) |
| 1-3. | VG1644499129 | [1] | ELEMENT | KOBKIT (FOR A2,A3) |
| 4. | VG1644299010 | [1] | COVER ASSY (FOR A1) | |
| 4. | VG1644299012 | [1] | COVER (FOR A2,A3) | |
| 5. | VG1644599107 | [1] | CASE (FOR A1) | CASE (FOR A1) |
| 5. | VG1644599104 | [1] | CASE (FOR A2) | |
| 5. | VG1644599113 | [1] | CASE (FOR A3) | |
| 6. | VG1644699004 | [1] | SCREW | KOBCENTER (FOR A1) |
| 6. | VG1644699006 | [1] | BOLT-CENTER (FOR A2,A3) | |
| 7. | VG1644990001 | [1] | SPRING | KOBSET (FOR A1) |
| 7. | VG1644999003 | [1] | SPRING | KOB(FOR A2,A3) |
| 8. | VG1645090001 | [1] | WASHER | KOBSET (FOR A1) |
| 8. | VG1645099000 | [1] | RETAINER | KOBWASHER-SET (FOR A2,A3) |
| 9. | VG1645290001 | [1] | DRAIN PLUG | KOB(FOR A1) |
| 9. | VG0893144010 | [1] | PLUG | KOBDRAIN (FOR A2,A3) |
| 10. | VG0998120800 | [1] | PACKING (FOR A1) | |
| 10. | VG0998111000 | [1] | GASKET | KOBPACKING (FOR A2,A3) |
