神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (07-003) - GENERATOR, (INNER PARTS), (SAWAFUJI MAKE) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
188 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-43. | VG2310096102 | [1] | ALTERNATOR | KOB(AX3) |
| 1. | VG2310899012 | [1] | ROTOR | KOB |
| 2. | VG2312699001 | [1] | RETAINER-GREASE | |
| 3. | VG2312099003 | [1] | BALL BEARING | KOB |
| 4. | VG0092651900 | [1] | KEY | KOBWOODRUFF |
| 5. | VG2310299009 | [1] | STATOR | KOBCOIL |
| 16-22. | VG2312799018 | [1] | U-BRACKET | KOBCOVER ASSY REAR |
| 16. | VG2312899014 | [1] | BRACKET COVER-REAR | BRACKET COVER-REAR |
| 17. | VG2310999000 | [1] | HEAT CONTACTOR | KOBB |
| 18. | VG2310999001 | [1] | DIODE | KOBHEAT,E |
| 19. | VG2315099008 | [1] | TERMINAL ASSY | TERMINAL ASSY |
| 20. | VG2315799009 | [3] | SCREW SET ASSY | SCREW SET ASSY |
| 21. | VG2314790005 | [2] | BOLT | BOLT |
| 22. | VG2316599015 | [1] | COUPLING | KOBASSY |
| 24-26. | VG2313399010 | [1] | BRUSH HOLDER | KOB |
| 26. | VG2313599006 | [2] | BRUSH ASSY | BRUSH ASSY |
| 27-34. | VG2311899008 | [1] | COVER ASSY-FRONT | |
| 27. | VG2311999010 | [1] | COVER-FRONT | |
| 29. | VG2314599008 | [1] | PROTECTOR | |
| 30. | VG2320699000 | [1] | COVER | |
| 31. | VG2315799014 | [4] | SCREW | SCREW |
| 32. | VG2313099000 | [1] | BALL BEARING | KOB |
| 33. | VG2311799005 | [1] | COVER | |
| 34. | VG2311699003 | [1] | FELT | KOB |
| 40. | VG2315199016 | [1] | PULLEY | KOBASSY-FAN Superseded by part number: VG2315199102 |
| 41. | VG2313199006 | [3] | BOLT THROUGH | BOLT THROUGH |
| 43. | VG2315290004 | [1] | NUT ASSY-PULLEY | NUT ASSY-PULLEY |
