纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (2.325[02E]) - HYDROSTATIC DRIVE PUMPS - HYDROSTATIC PUMP DC 100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
765 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76607188 | [1] | HYDRAULIC PUMP | MAC |
| 3. | 76607189 | [1] | COVER | MACASSY. - FOR SERVICE COMPONENTS SEE FIG. 2.325 (03) |
| 4. | 76607190 | [1] | SUPPORT | MACASSY. - FOR SERVICE COMPONENTS SEE FIG. 2.325 (06) |
| 8. | 76593142 | [1] | COVER | MAC |
| 9. | 76593143 | [1] | COVER | MAC |
| 13. | 76607191 | [1] | PIN | MAC |
| 24. | 76607192 | [1] | SCREW | MAC |
| 26. | 76593147 | [1] | SCREW | MAC |
| 28. | 76593148 | [2] | DIAPHRAGM | MAC Superseded by part number: 87753562 |
| 31. | 76593149 | [2] | PIN | MAC |
| 49. | 76593150 | [1] | DIAPHRAGM | MAC |
| 50. | 76609861 | [1] | HYDRAULIC PUMP | MAC- HYDROSTATIC |
