纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (2.325[03C]) - HYDROSTATIC DRIVE PUMPS - COVER ASSY. DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
495 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76609842 | [2] | HYDRAULIC VALVE | MAC- FOR SERVICE COMPONENTS SEE FIG. 2.325 (04) Superseded by part number: 47628203 |
| 2. | 76609843 | [1] | HYDRAULIC VALVE | MAC |
| 3. | 76609844 | [1] | SHUT-OFF VALVE | MAC Superseded by part number: 47628199 |
| 7. | 76609845 | [4] | SCREW | MAC |
| 8. | 76609846 | [2] | ROLL PIN | MAC |
| 43. | 76609847 | [1] | BUSHING | MAC |
| 44. | 76609848 | [1] | BUSHING | MAC Superseded by part number: 1456673 |
| 45. | 76607189 | [1] | COVER | MACASSY. |
