凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (09.01[01]) - AUTOMATIC LUBRICATION Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
438 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80431352
|
[1] |
CLAMP
|
ZED
Superseded by part number: 431352
|
| 2. |
80323597
|
[1] |
STRAP
|
ZED
Superseded by part number: 14560287
|
| 3. |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
|
| 4. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 5. |
80378243
|
[2] |
WASHER
|
ZED
8MM Superseded by part number: 378243
|
| 6. |
80120106
|
[2] |
SCREW,M8 x 40mm
|
ZED
M8x40 Superseded by part number: 16044024
|
| 7. |
80120109
|
[2] |
SCREW
|
ZED
M10x20 Superseded by part number: 43138
|
| 8. |
80140045
|
[2] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 9. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
84025697
|
[1] |
SUPPORT
|
PLO
|
| 11. |
15896221
|
[2] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 12. |
80322357
|
[2] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 13. |
80300508
|
[2] |
SCREW
|
ZED
M6x45 Superseded by part number: 86977790
|
| 14. |
84025121
|
[1] |
CAM
|
PLO
|
| 15. |
84015600
|
[6] |
BUSHING,16mm ID x 25mm OD x 12mm L
|
ZED
|
| 16. |
84025132
|
[6] |
COMMUTATOR BRUSH
|
POL
Superseded by part number: 89835044
|
| 17. |
84025133
|
[6] |
ELBOW
|
POL
Superseded by part number: 84012698
|
| 18. |
89817682
|
[6] |
NUT
|
ZED
Superseded by part number: 576895
|
| 19. |
84025675
|
[1] |
BUMPER
|
PLO
|
| 20. |
84025896
|
[1] |
RETAINER COLLAR
|
POL
Superseded by part number: 301592731
|
