神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (05-012) - CONTROL-FUEL, ( LEVER) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
774 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG1684897005 | [1] | SUPPORT SPRING (FOR A1,A3,A4,A5) | SUPPORT SPRING (FOR A1,A3,A4,A5) |
| 1. | VG1684896006 | [1] | SUPPORT-SPRING (FOR A7) | |
| 1. | VG1684896005 | [1] | SUPPORT-SPRING (FOR A7) | |
| 2. | VG1933396004 | [1] | SEAT-SPRING (FOR A3,A4,A5) | |
| 3. | VG2176690007 | [1] | SPACER (FOR A1,A3,A4,A5) | SPACER (FOR A1,A3,A4,A5) |
| 4. | VG0112100074 | [1] | SPECIAL WASHER | KOB(FOR A1,A3,A4,A5) |
| 4. | VG0812109010 | [1] | BOLT (FOR A1,A3,A4,A5) | BOLT (FOR A1,A3,A4,A5) |
| 6. | VG1684996001 | [1] | SPRING | KOB(FOR A1,A5) |
| 6. | VG1684996002 | [1] | SPRING-RETURN (FOR A7) | |
| 7. | VG1684990104 | [1] | SPRING | KOB(FOR A1,A3,A4) |
| 8. | VG1684496009 | [1] | BOOTS-SPRING (FOR A1,A5) | |
| 9. | VG1823896006 | [1] | LEVER-CONTROL (FOR A1,A5) | |
| 9. | VG1933296004 | [1] | LEVER-CONTROL (FOR A4,A10) | |
| 11. | VG0891513810 | [1] | WASHER SPRING (FOR A7) | WASHER SPRING (FOR A7) |
| 12. | VG0812062028 | [2] | BOLT W/WASHER (FOR A1,A4,A5,A10) | BOLT W/WASHER (FOR A1,A4,A5,A10) |
| 12. | VG0811082062 | [1] | BOLT | KOBBOLT,W/WASHER (FOR A7) |
| 13. | VG1933397001 | [1] | SEAT HOOK (FOR A1,A5) | SEAT HOOK (FOR A1,A5) |
| 14. | VG0891110610 | [1] | NUT | KOB(FOR A1,A5) Superseded by part number: 76601954 |
| 15. | VG0891513610 | [1] | WASHER SPRING (FOR A1,A5) | WASHER SPRING (FOR A1,A5) |
| . . | FIGURE NOTE: | [1] | NEW KEY NO.1+2(FOR A1,A3,A4,A5)(8403) | |
