凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (09.03[01]) - 4-WAY MANIFOLD Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
827 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84012721
|
[1] |
DUCT
|
PLO
|
| 2. |
84025131
|
[2] |
HYD CONNECTOR
|
PLO
DIA:8MM
|
| 3. |
80323597
|
[2] |
STRAP
|
ZED
Superseded by part number: 14560287
|
| 4. |
84012863
|
[2] |
REDUCER
|
PLO
IM25
|
| 5. |
84012689
|
[1] |
REDUCER
|
ZED
IM22
|
| 6. |
84025142
|
[1] |
REDUCER
|
PLO
IM23 Superseded by part number: 84036721
|
| 7. |
89817659
|
[1] |
TUBE
|
PLO
DIA:4MM,L=3M Superseded by part number: 9817659
|
| 8. |
84025138
|
[1] |
TUBE
|
PLO
|
| 9. |
84025143
|
[1] |
TUBE
|
PLO
Superseded by part number: 84025138
|
| 10. |
84025141
|
[1] |
TUBE,8 mm Diameter, 900 mm Length
|
POL
DIA:8MM,L=900MM Superseded by part number: 84025140
|
| 11. |
84025140
|
[1] |
TUBE,8 mm Diameter, 4250 mm Length
|
POL
DIA:8MM,L=4250MM Superseded by part number: 322659850
|
| 12. |
89835041
|
[3] |
PLUG
|
PLO
Superseded by part number: 9835041
|
