纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (2.339[03E]) - FRICTION FOR TRAVEL JOYSTICK - DC100 STD. S/N 13111093 & DOWN; LGP S/N 13115016 & DOWN New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
1006 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76606092 | [1] | SWITCH ASSY | MAC- CRUISE CONTROL |
| 2. | 76606094 | [1] | ELECTRIC CABLE | MAC- CRUISE CONTROL |
| 3. | 76606096 | [1] | TIE-ROD | MAC |
| 4. | 76606095 | [1] | CAP WASHER | MAC |
| 5. | 76606097 | [1] | SUPPORT | MAC |
| 6. | 76590749 | [2] | SCREW | MAC Superseded by part number: 86508568 |
| 7. | 76590873 | [5] | WASHER | MAC Superseded by part number: 10519404 |
| 8. | 76590934 | [3] | NUT | MAC Superseded by part number: 12574221 |
| 9. | 76590715 | [1] | NUT | MAC |
| 10. | 76590716 | [2] | WASHER | MAC |
| 11. | 76606101 | [7] | NUT | MAC |
| 12. | 76606102 | [1] | LEVER | MAC |
| 13. | 76606103 | [1] | ELECTROMAGNET | MAC |
| 14. | 76606104 | [1] | SUPPORT | MAC |
| 16. | 76606119 | [1] | PIN | MAC |
| 17. | 76595957 | [1] | SCREW | MAC |
| 18. | 76606120 | [7] | SCREW | MAC |
