纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (9.380[03]) - HYDROSTATIC DRIVE COUPLER - OIL LEVEL KIT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
911 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 47323000 | [1] | KIT | MACIncludes ref, Serial Range: 1-8 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 2. | 47323074 | [1] | BRACKET | MAC |
| 3. | 76590714 | [2] | SCREW | MAC Superseded by part number: 9515003 |
| 4. | 76590713 | [4] | WASHER | MAC Superseded by part number: 14496621 |
| 5. | 47323073 | [2] | NUT | MAC Superseded by part number: 190003888452 |
| 6. | 76591286 | [1] | SCREW | NH Superseded by part number: 86629541 |
| 7. | 76593024 | [1] | CLAMP | MAC |
| 8. | 47323072 | [1] | CLAMP | MAC |
