凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (13.03[01]) - PICK-UP Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
891 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80130012
|
[2] |
COTTER PIN
|
ZED
5x50 Superseded by part number: 87400
|
| 2. |
84025454
|
[1] |
SPINDLE,28.57mm OD x 255mm L
|
PLO
|
| 3. |
80140119
|
[3] |
WASHER
|
ZED
Superseded by part number: 140119
|
| 4. |
86637251
|
[2] |
DRIVEN SPROCKET
|
NH
|
| 5. |
80578189
|
[4] |
FLANGE
|
ZED
Superseded by part number: 86620026
|
| 6. |
80121602
|
[2] |
BALL BEARING
|
ZED
Superseded by part number: 121602
|
| 7. |
80573558
|
[1] |
SHIELD
|
PA
Superseded by part number: 573558
|
| 8. |
80442293
|
[1] |
WASHER
|
ZED
Superseded by part number: 442293
|
| 9. |
80130421
|
[1] |
WASHER
|
ZED
Superseded by part number: 130421
|
| 10. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 11. |
80140045
|
[6] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 12. |
84025107
|
[1] |
SPINDLE
|
PLO
|
| 13. |
80120109
|
[3] |
SCREW
|
ZED
M10x30 Superseded by part number: 43138
|
| 14. |
84822007
|
[28] |
GUARD
|
PLO
|
| 15. |
84822009
|
[1] |
GUARD
|
PLO
|
| 16. |
16043224
|
[1] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
|
| 20. |
84100188
|
[1] |
DIA KIT, HARVESTER
|
PLO
|
