凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (13.04[01]) - WINDGUARD Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
202 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84822017
|
[1] |
SHROUD
|
PLO
|
| 2. |
84822019
|
[3] |
FINGER
|
PLO
|
| 4. |
80120037
|
[7] |
BOLT
|
ZED
M8x20 Superseded by part number: 86507486
|
| 5. |
84024952
|
[7] |
CLAMP,10mm ID
|
PLO
|
| 6. |
80322358
|
[8] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 7. |
43362
|
[8] |
NUT,M8 x 1.25, Cl 10
|
BHB
|
| 8. |
89832679
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 9832679
|
| 9. |
84000320
|
[2] |
WASHER
|
ZED
|
| 10. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 11. |
84025061
|
[1] |
CHAIN
|
PLO
|
| 12. |
84025509
|
[2] |
CHAIN,180mm L
|
PLO
|
| 13. |
80120100
|
[2] |
BOLT,M6 x 1 x 20mm
|
ZED
Superseded by part number: 120100
|
| 14. |
80140015
|
[2] |
WASHER
|
ZED
6MM Superseded by part number: 86588450
|
| 15. |
80322357
|
[2] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 16. |
15896221
|
[2] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 17. |
84822018
|
[2] |
FINGER,Formed, 2 Prongs, 382mm L
|
PLO
L=112MM
|
| 18. |
84822003
|
[1] |
FINGER
|
PLO
RH,L=112x215MM
|
| 20. |
84822023
|
[1] |
FINGER
|
PLO
LH,L=112x215MM
|
