神钢零件查询(F4GE9484A J600) - ENGINE 504120790 - 87052264 (1/07-12/10) (0.32.3) - PIPING - ENGINE COOLING SYSTEM (2852921-2852149) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
579 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852923 | [3] | SCREW | TORM10X80 Superseded by part number: 16593025 |
| 2. | 2854072 | [2] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 3. | 2852392 | [1] | SUPPORT | TOR- ASSY Superseded by part number: 500387647 |
| 4. | 4895576 | [2] | DOWEL | TOR |
| 5. | 2852922 | [1] | ELBOW | TOR Superseded by part number: 504042847 |
| 6. | 4895392 | [2] | HEX SOCKET PLUG,M18 x 1.5 | TOR- Assy |
| 7. | 4895393 | [2] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 8. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TOR- Assy |
| 9. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
