神钢零件查询(F4GE9484A J600) - ENGINE 504120790 - 87052264 (1/07-12/10) (0.32.6) - THERMOSTAT - ENGINE COOLING SYSTEM (2853444-2855071-2852156) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
341 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899091 | [3] | SCREW,Hex Flange Cap, M8 x 1.25 x 40.00mm | BAS |
| 2. | 2853131 | [1] | HOUSING | TOR Superseded by part number: 504079269 |
| 3. | 2853445 | [1] | BRACKET | TOR Superseded by part number: 504079607 |
| 4. | 2853133 | [1] | GASKET,51.5mm ID x 61.5mm OD x 16.5mm Thk | TOR Superseded by part number: 504078856 |
| 5. | 2858050 | [1] | THERMOSTAT,60.8mm OD | TOR- ASSY, OD=60.8mm Superseded by part number: |
| 7. | 2852473 | [1] | GASKET,53.62mm ID x 59.72mm OD x 4.01mm Thk | TOR Superseded by part number: 504030960 |
| 7. | 84325989 | [1] | SEAL | TORUse For 84383461 |
