神钢零件查询(F4GE9484A J600) - ENGINE 504120790 - 87052264 (1/07-12/10) (0.34.5) - FAN DRIVE (2854590-2855347-2856375) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
824 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852396 | [1] | BELT TENSIONER | TOR Superseded by part number: |
| 2. | 4890732 | [1] | RETAINER,11.50mm ID x 52mm OD x 7mm | TOR |
| 4. | 2852397 | [1] | IDLER,65mm OD | TOR Superseded by part number: 504065878 |
| 5. | 2852398 | [1] | IDLER WHEEL,65mm OD | TOR Superseded by part number: 504065877 |
| 6. | 4899053 | [4] | SCREW,Hex Flg, M8 x 45 | TOR |
| 7. | 2852245 | [1] | PULLEY,65mm OD | TOR Superseded by part number: 504065879 |
| 8. | 2852171 | [1] | SNAP RING | TOR Superseded by part number: 32324 |
| 9. | 4892426 | [1] | HUB | TOR |
| 10. | 4892732 | [1] | BALL BEARING,34mm ID x 64mm OD x 37mm W | TOR |
| 11. | 2852172 | [1] | BOLT,Flng, M10 x 1.5 x 70mm | TORM10 x 70 Superseded by part number: 16676834 |
| 13. | 4899032 | [4] | SCREW,Hex Flg, M10 x 1.5 x 25 | TOR |
