凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (15.23B[01]) - CHAIN AND ROLLS - GEARBOX - C651 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
498 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84821115
|
[1] |
GEARBOX
|
PLO
, Serial Range: (2-19)
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| 6. |
84819506
|
[1] |
GEAR
|
PLO
|
| 7. |
84819507
|
[1] |
CIRCLIP
|
PLO
|
| 8. |
84819508
|
[1] |
GASKET
|
PLO
|
| 9. |
89811496
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 84819080
|
| 10. |
84032776
|
[2] |
SEAL
|
ZED
SEALRING
|
| 11. |
84819509
|
[1] |
HUB
|
PLO
|
| 12. |
84819510
|
[1] |
GEAR
|
PLO
|
| 13. |
80300633
|
[1] |
SNAP RING,M80, Int
|
ZED
Superseded by part number: 300633
|
| 14. |
80370008
|
[1] |
SNAP RING,M50, Ext
|
ZED
Superseded by part number: 8603209
|
| 15. |
84819511
|
[1] |
PLUG
|
PLO
|
| 16. |
84819512
|
[2] |
PLUG
|
PLO
|
| 17. |
84819497
|
[1] |
ROLLER BEARING
|
PLO
Superseded by part number: 24903830
|
| 18. |
84819513
|
[1] |
GASKET
|
PLO
|
