斗山零件查询ACOUSTIC FOAM DX360LCA(S/N:5950~) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
611 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
180102-00337
|
[-] |
|
|
| 1. |
110508-04848A
|
[1] |
|
|
| 1. |
110508-04848B
|
[1] |
|
|
| 12. |
S0509066
|
[6] |
BOLT
|
|
| 13. |
S5102503
|
[6] |
. WASHER
|
|
| 14. |
2114-1058D29
|
[6] |
WASHER
|
|
| 15. |
161-00614
|
[1] |
FOAM
|
|
| 16. |
K1009110
|
[1] |
FORM;POLYURETHANE
|
|
| 17. |
K1001029
|
[10] |
BOLT
|
|
| 2. |
110508-04849B
|
[1] |
|
|
| 2. |
110508-04849A
|
[1] |
|
|
| 3. |
110508-04850B
|
[1] |
|
|
| 3. |
110508-04850A
|
[1] |
|
|
| 4. |
110508-04851B
|
[1] |
|
|
| 4. |
110508-04851A
|
[1] |
|
|
| 5. |
110508-23806
|
[1] |
|
|
| 5. |
110508-16882
|
[1] |
|
|
| 6. |
180102-01281
|
[1] |
|
|
| 6. |
K1004636
|
[1] |
FOAM
|
|
| 7. |
K1005837
|
[1] |
FOAM;POLYURETHANE
|
|
| 8. |
K1005835A
|
[1] |
FOAM;POLYURETHANE
|
|
| 9. |
K1005836
|
[1] |
FOAM;POLYURETHANE
|
|
