| 1. |
86643779
|
[1] |
DIA KIT, HARVESTER
|
NH
6 Bar Conversion, Includes: Ref. 2 - 18 & Instructions
|
| 2. |
9618968
|
[18] |
WASHER,0.41" ID x 0.78" OD x 0.1" Thk
|
NH
Plated, HT
|
| 3. |
86635216
|
[2] |
ARM
|
NH
|
| 4. |
86635045
|
[2] |
ANGLE
|
NH
|
| 5. |
638025
|
[2] |
FLANGE
|
NH
|
| 6. |
905-10020
|
[8] |
BOLT,Hex Flg, M10 x 20mm
|
CAS
Superseded by part number: 274249
|
| 7. |
84350126
|
[2] |
CAM FOLLOWER,1/2" - 20 x 38mm OD x 54.5mm L
|
NH
|
| 8. |
136521
|
[2] |
COTTER PIN,5.7mm OD x 44.45mm L
|
NH
Hardened, 1/4" x 1-3/4"
|
| 9. |
814-10060
|
[2] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 120070
|
| 10. |
814-10050
|
[4] |
BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 120069, 47110242
|
| 11. |
832-46410
|
[18] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 12. |
88130
|
[2] |
NUT,1/2"-20, GC
|
NH
|
| 13. |
495-11053
|
[4] |
WASHER,1/2", SAE
|
CAS
Superseded by part number: 87364, 72187259
|
| 14. |
54770
|
[2] |
BALL BEARING,27.33 mm ID x 47.092 mm OD x 25.4 mm
|
NH
Superseded by part number: 84330047
|
| 15. |
54695
|
[2] |
BEARING HOUSING
|
NH
|
| 16. |
825-51410
|
[12] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 17. |
614-10030
|
[16] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 18. |
87394242
|
[56] |
TORSION SPRING,Coiled, 2 Prong, 186.5mm L
|
NH
Pickup, Curved, Premium, Standard
|
