纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (9.500[04B]) - RIPPER CYLINDER DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76606849 | [2] | CYLINDER | MACCYLINDER, HYDRAULIC |
| 2. | 76591112 | [2] | LUBE NIPPLE | MAC |
| 3. | 76606831 | [1] | CYLINDER | MACHOUSING, CYLINDER |
| 4. | 76591124 | [4] | ARTICULATION | MAC Superseded by part number: 79037239 |
| 5. | 76591222 | [1] | SCREW | MAC |
| 6. | 76605923 | [1] | PISTON | MAC |
| 11. | 76605914 | [1] | BUSHING | MAC |
| 16. | 76610338 | [1] | ROD | MACROD, CYLINDER |
| 17. | 76605911 | [1] | SEAL KIT | MAC Superseded by part number: 8403291, 8210979, 8207016, Z282186, 6904034, BER4149142, A2982180, E1182158 |
| 18. | 76591125 | [4] | LOCKING RING | MAC Superseded by part number: 11061376 |
