纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (9.550[01C]) - TRACK ROLLER GUARD DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
696 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76609947 | [2] | SHIELD | MACGUARD |
| 2. | 76595959 | [4] | NUT | MAC Superseded by part number: 12577721 |
| 3. | 76605604 | [8] | WASHER | MAC |
| 4. | 76609948 | [4] | STUD | MACTIE-ROD |
| 5. | 76609949 | [4] | SPACER | MAC |
| 6. | 76605609 | [16] | PAD | MAC |
| 7. | 76609950 | [2] | SHIELD | MACGUARD |
| 8. | 76590722 | [16] | SCREW | MAC Superseded by part number: 43167 |
| 9. | 76598266 | [16] | LOCK WASHER | MACWASHER, LOCK Superseded by part number: 11194274 |
| 10. | 76609927 | [1] | KIT | MACTRACK GUARD KIT - Consist of Refs. 1 - 9. |
